Military Ra 105

General characteristics

HAM bands

6m

Frequency stability

?

Tuning steps

100 kHz

Memories

?

Receiver

RX-range

38-55 MHz

Modulations

FM

Sensitivity

?

Selectivity

?

Filters

?

Receiver system

?

IF-frequencies

?

Image rejection

?

Audio output

External handset

Transmitter

TX-range

?

Modulations

FM

RF-output

0.9 W

Connections

Antenna

BNC + Proprietary (military)

Impedance

50Ω

Other

-

Electrical

Power requirements

1.5, -6, 67.5 and 135 V DC 12 V DC from battery pack and a built-in voltage converter

Current drain RX

?

TX

?

Physical

Dimensions (w×h×d)

265 × 455 × 85 mm (10.43 × 17.91 × 3.35 in) without battery pack

Weight

4.60 kg (10.1 lbs)

Form factor

Mobile

Manufactured

Between 196x and 197x in Sweden by SRA

Other features

Usage

Military communication

Features + options

-

Accessories

-

RigReference ID

5203

MPN

MILITARY-RA-000105

Manuals, diagrams and brochures

Ra 105 Original power supply circuit diagram JPG - Unknown size, submitted by RigReference

Ra 105 Replacement power supply circuit diagram JPG - Unknown size, submitted by RigReference



Upload relevant documents

Reviews

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Military Ra 105. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic price data, today's estimated value of the Military Ra 105 in Good condition is around:

• EUR 8 ~ EUR 29
