New price 2001 in the UK: 99.95

General characteristics

HAM bands
70cm
Frequency stability
?
Tuning steps
5-50 kHz
Memories
100 channels in 1 bank(s)

Receiver

RX-range
430-440 MHz
Modulations
FM
Sensitivity
?
Selectivity
6 kHz (-6 dB), 14 kHz (-60 dB)
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
60 dB
Audio output
?

Transmitter

TX-range
430-440 MHz
Modulations
FM
RF-output
High: 1 W, Low: 200 mW

Connections

Antenna
SMA
Impedance
50 Ω
Other
-

Electrical

Power requirements
3.6-4.5V DC
Current drain RX
15-40 mA
TX
Max 600 mA

Physical

Dimensions (w×h×d)
56 × 102 × 28 mm (2.20 × 4.02 × 1.10 in)
Weight
160 gr (5.6 oz) with batteries
Form factor
Handheld
Manufactured
Between 2001 and 200x

Other features

Usage
Amateur / Ham radio operators
Features + options
CTCSS & theft alarm
Accessories
-
RigReference ID
2280
MPN
ALINCO-DJ-S000040

Manuals, diagrams and brochures

Alinco DJ-S40 Instruction manual PDF - Unknown size, submitted by RigReference
Alinco DJ-S40T Service manual PDF - Unknown size, submitted by RigReference
