General characteristics

HAM bands
70cm
Frequency stability
?
Tuning steps
5 / 8.33 / 10 / 12.5 / 15 / 20 / 25 / 30 / 50 kHz
Memories
100 channels in 1 bank(s)

Receiver

RX-range
350-512 MHz
Modulations
FM   N-FM   DV
Sensitivity
0.25 µV (12 dB SINAD)
Selectivity
FM: 12 kHz (-6 dB), 28 kHz (-60 dB)
N-FM: 6 kHz (-6 dB), 14 kHz (-60 dB)
Filters
?
Receiver system
Double-conversion superheterodyne
IF-frequencies
1st: 30.85 MHz
2nd: 455 KHz
Image rejection
?
Audio output
?

Transmitter

TX-range
430-440 MHz
Modulations
FM   N-FM   DV
RF-output
High: 35 W, Medium: 20 W, Low: 5 W

Connections

Antenna
-
Impedance
50 Ω
Other
-

Electrical

Power requirements
11.7-15.8V DC
Current drain RX
400-600 mA
TX
Max 10 A

Physical

Dimensions (w×h×d)
142 × 40 × 174 mm (5.59 × 1.57 × 6.85 in)
Weight
1,000 gr (2.2 lbs)
Form factor
Mobile
Manufactured
Between 2007 and 200x

Other features

Usage
Amateur / Ham radio operators
Features + options
1K2/9K6 TNC option (EJ-41U), GPS input for APRS. CTCSS, DCS Theft alarm. RoHS compliant
Accessories
-
RigReference ID
2324
MPN
ALINCO-DR-000435E-MKIII

Manuals, diagrams and brochures

Alinco DR-135/435MK3 FXE Instruction manual PDF - Unknown size, submitted by RigReference
Alinco DR-135/435MK3 Service manual PDF - Unknown size, submitted by RigReference

Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Alinco DR-435E MKIII. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Alinco DR-435E MKIII is around:

  • EUR 82.00 ~ EUR 41.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2013 EUR 259.00 Used / Good thiecom.de
2010 EUR 259.00 New / Good thiecom.de
