New price 1994 in the US: $699.00

General characteristics

HAM bands
160m  80m  40m  30m (WARC)  20m  17m (WARC)  15m  12m (WARC)  10m
Frequency stability
?
Tuning steps
?
Memories
?

Receiver

RX-range
10-160 m + WARC
Modulations
CW   SSB
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

TX-range
10-160 m + WARC
Modulations
CW   SSB
RF-output
SSB: 150 W (PEP input), CW: 120 W

Connections

Antenna
SO-239
Impedance
50 Ω
Other
-

Electrical

Power requirements
12-14V DC
Current drain RX
0.5 A
TX
Max 20 A

Physical

Dimensions (w×h×d)
228 × 86 × 228 mm (8.98 × 3.39 × 8.98 in)
Weight
3.18 kg (7.0 lbs)
Form factor
Base Station
Manufactured
Between 1994 and 199x in USA

Other features

Usage
Amateur / Ham radio operators
Features + options
Full QSK
Accessories
-
RigReference ID
2384
MPN
ATLAS-000400-X

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Reviews & stories

Rating Title Submitted
Atlas 400 10 years ago by ras5cal

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Atlas 400-X. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Atlas 400-X is around:

  • USD 380.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2011 USD 1200.00 Used / Good ras5cal
