General characteristics

HAM bands
6m
Frequency stability
?
Tuning steps
?
Memories
?

Receiver

RX-range
50-54 MHz
Modulations
FM
Sensitivity
0.16 µV (12 dB SINAD)
Selectivity
12 kHz (-6 dB), 30 kHz (-60 dB)
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
60 dB
Audio output
?

Transmitter

TX-range
50-54 MHz
Modulations
FM
RF-output
High: 5 W, Low: 0.5 W

Connections

Antenna
-
Impedance
50 Ω
Other
-

Electrical

Power requirements
6.3-16V DC
Current drain RX
28-150 mA
TX
0.5-1 A

Physical

Dimensions (w×h×d)
60 × 174 × 33 mm (2.36 × 6.85 × 1.30 in)
Weight
550 gr (1.2 lbs)
Form factor
Unknown
Manufactured
Between 200x and 200x in Japan

Other features

Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-
RigReference ID
2417
MPN
AZDEN-AZ-000061

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Azden AZ-61. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Azden AZ-61 is around:

  • USD 429.00 ~ USD 12.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2016 USD 450.00 New / Mint rreh917
1995 USD 400.00 New / Mint rreh917
