General characteristics

HAM bands
2m
Frequency stability
?
Tuning steps
12.5 kHz
Memories
16 channels in 1 bank(s)

Receiver

RX-range
144-148 MHz
Modulations
FM
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

TX-range
144-148 MHz
Modulations
FM
RF-output
High: 25 W, Low: 5 W

Connections

Antenna
SO-239
Impedance
50 Ω
Other
-

Electrical

Power requirements
13.8V DC
Current drain RX
?
TX
Max 5 A

Physical

Dimensions (w×h×d)
140 × 50 × 172 mm (5.51 × 1.97 × 6.77 in)
Weight
?
Form factor
Mobile
Manufactured
Between 1983 and 19xx

Other features

Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-
RigReference ID
2421
MPN
AZDEN-PCS-004000

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Azden PCS-4000. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Azden PCS-4000 is around:

  • GBP 1.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
1985 GBP 100.00 Used / Fair Mike CRABTREE
