Yaesu FT-230R

Mobile VHF Transceiver

Specs Manuals (0) Reviews (1) Prices (0) Compare

The Yaesu FT-230R is a mobile VHF transceiver. Frequency range for both RX and TX is 144-146 MHz (Europe) or 144-148 MHz (USA). RF output is selectable between High: 25 W and Low: 3 W. It features 1 memory bank with 10 channels. Power requirement is 13.8V DC. Current drain in RX is Max 300 mA, and Max 5 A in TX. Dimensions are 50 × 150 × 174 mm.

General characteristics

HAM bands: 2m
Frequency stability: ?
Tuning steps: ?
Memories: 10 channels in 1 bank(s)

Receiver

RX-range: 144-146 MHz (Europe)
144-148 MHz (USA)
Modulations: FM
Sensitivity: ?
Selectivity: ?
Filters: ?
Receiver system: ?
IF-frequencies: ?
Image rejection: ?
Audio output: ?

Transmitter

TX-range: 144-146 MHz (Europe)
144-148 MHz (USA)
Modulations: FM
RF-output: High: 25 W, Low: 3 W

Connections

Antenna: SO-239
Impedance: 50 Ω
Other: -

Electrical

Power requirements: 13.8V DC
Current drain RX: Max 300 mA
TX: Max 5 A

Physical

Dimensions (w×h×d): 150 × 50 × 174 mm (5.91 × 1.97 × 6.85 in)
Weight: 1.30 kg (2.9 lbs)
Form factor: Mobile
Manufactured: Between 1983 and 19xx

Other features

Usage: Amateur / Ham radio operators
Features + options: -
Accessories: -
RigReference ID: 4264
MPN: YAESU-FT-000230R
