General characteristics

HAM bands
2m
Frequency stability
?
Tuning steps
?
Memories
?

Receiver

RX-range
144-146 MHz (Europe)
142-149 MHz (USA)
Modulations
FM
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

TX-range
144-146 MHz (Europe)
142-149 MHz (USA)
Modulations
FM
RF-output
High: 45 W, Low: 5 W

Connections

Antenna
SO-239
Impedance
50 Ω
Other
-

Electrical

Power requirements
13.8V DC
Current drain RX
0.5-0.9 A
TX
3-9.5 A

Physical

Dimensions (w×h×d)
175 × 64 × 220 mm (6.89 × 2.52 × 8.66 in)
Weight
1.90 kg (4.2 lbs)
Form factor
Mobile
Manufactured
Between 1983 and 19xx

Other features

Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-
RigReference ID
3465
MPN
KENWOOD-TR-007950

Manuals, diagrams and brochures

Kenwood TR-7950 Instruction Manual PDF - Unknown size, submitted by RigReference

Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Kenwood TR-7950. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Kenwood TR-7950 is around:

  • EUR 32.00
  • USD 145.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2020 USD 152.50 Used / Okay eBay
2015 EUR 65.00 Used / Mint EI3HDB
