4 extra 500 kHz ranges with optional XTAL's. The Drake RR-2 is the same receiver, but with continuous range.
General characteristics
- HAM bands
- 6m
- Frequency stability
- ?
- Tuning steps
- ?
- Memories
- ?
Receiver
- RX-range
- 0.15-0.535 / 1.5-4 / 4-4.5 / 6-6.5 / 8-9 / 12-13.5 / 16-17.5 / 22-23 / 25-26 MHz
- Modulations
- AM CW SSB
- Sensitivity
- ?
- Selectivity
- ?
- Filters
- ?
- Receiver system
- ?
- IF-frequencies
- ?
- Image rejection
- ?
- Audio output
- ?
Connections
- Antenna
- -
- Impedance
- 50/500Ω
- Other
- -
Electrical
- Power requirements
- 24V DC or mains
- Current drain RX
- ?
- TX
- -
Physical
- Dimensions (w×h×d)
- 482 × 178 × 279 mm (18.98 × 7.01 × 10.98 in)
- Weight
- 6.40 kg (14.1 lbs)
- Form factor
- Base Station
- Manufactured
- Between 19xx and 19xx
Other features
- Usage
- Amateur / Ham radio operators
- Features + options
- -
- Accessories
- -
- RigReference ID
- 2586
- MPN
- DRAKE-RR-000001
