General characteristics

HAM bands
2m
Frequency stability
?
Tuning steps
?
Memories
23 channels in 1 bank(s)

Receiver

RX-range
144-148 MHz
Modulations
FM
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
XTAL
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

TX-range
144-148 MHz
Modulations
FM
RF-output
High: 10 W, Low: 1 W

Connections

Antenna
SO-239
Impedance
50 Ω
Other
-

Electrical

Power requirements
11-16V DC or mains
Current drain RX
Max 0.6 A
TX
Max 2.7 A

Physical

Dimensions (w×h×d)
180 × 60 × 240 mm (7.09 × 2.36 × 9.45 in)
Weight
2.50 kg (5.5 lbs)
Form factor
Unknown
Manufactured
Between 19xx and 19xx

Other features

Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-
RigReference ID
2608
MPN
DRAKE-TR-000072

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Drake TR-72. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on similar Transceiver equipment, the estimated value of the Drake TR-72 is around:

  • USD 210 ~ USD 390

This estimate is based on similar equipment and may not reflect the exact value of this model.

These estimates are based on the following prices:
