10 dB attenuator. Sound squelch
General characteristics
- HAM bands
- ?
- Frequency stability
- ?
- Tuning steps
- 5 / 12.5 / 50 kHz
- Memories
- 400 channels in 10 bank(s)
Receiver
- RX-range
- 25-520 / 760-1300 MHz
- Modulations
- AM FM W-FM
- Sensitivity
- AM, 20 dB S/N
25-520 MHz: 2 µV
760-1100 MHz: 2 µV
1100-1300 MHz: 10 µV
FM, 20 dB S/N
25-520 MHz: 0.5 µV
760-1100 MHz: 0.5 µV
1100-1300 MHz: 3 µV
W-FM, 30 dB S/N
25-520 MHz: 3 µV
760-1100 MHz: 3 µV
1100-1300 MHz: 10 µV - Selectivity
- ?
- Filters
- ?
- Receiver system
- ? conversion superheterodyne
- IF-frequencies
- ?
- Image rejection
- ?
- Audio output
- ?
Connections
- Antenna
- -
- Impedance
- 50 Ω
- Other
- -
Electrical
- Power requirements
- 13.8V DC or mains
- Current drain RX
- ?
- TX
- -
Physical
- Dimensions (w×h×d)
- 220 × 76 × 205 mm (8.66 × 2.99 × 8.07 in)
- Weight
- 2.20 kg (4.9 lbs)
- Form factor
- Base Station
- Manufactured
- Between 19xx and 19xx
Other features
- Usage
- Amateur / Ham radio operators
- Features + options
- -
- Accessories
- -
- RigReference ID
- 2889
- MPN
- HANDIC-000080
