IP3 (HF/6m) +39 dBm New price 2006 in Germany: EUR 8799.-

General characteristics

HAM bands
160m  80m  40m  30m (WARC)  20m  17m (WARC)  15m  12m (WARC)  6m  10m
Frequency stability
?
Tuning steps
?
Memories
?

Receiver

RX-range
9 kHz - 52 MHz / 142-172 MHz
Modulations
AM   AM-sync   FM   W-FM   CW   USB   LSB
Sensitivity
AM
2 µV (1.8-54 MHz)
1.5 µV (142-172 MHz)
33 µV (9 kHz - 1.8 MHz)

FM
4 µV (1.8-54 MHz)
0.2 µV (142-172 MHz)
28 µV (9 kHz - 1.8 MHz)

SSB/CW
0.2 µV (1.8-54 MHz)
0.18 µV (142-172 MHz)
22 µV (9 kHz - 1.8 MHz)
Selectivity
AM 6 kHz
FM 12 kHz
SSB 2.4 kHz
CW 600 Hz
Filters
?
Receiver system
Double conversion superheterodyne
IF-frequencies
1st: 70.7 MHz
2nd: 10.698 (main), 10.702 (sub)
Image rejection
> 70 dB
Audio output
4.8 W (2×2.4 W main/sub)

Transmitter

TX-range
10-160 m + WARC / 6 m / 2 m
Modulations
AM   FM   CW   USB   LSB
RF-output
HF/6 m: 100 W, 2 m: 10 W

Connections

Antenna
SO-239
Impedance
50 Ω
Other
-

Electrical

Power requirements
13.8V DC
Current drain RX
?
TX
?

Physical

Dimensions (w×h×d)
425 × 175 × 465 mm (16.73 × 6.89 × 18.31 in) Width: 543 mm with rack handles
Weight
25.00 kg (55.2 lbs)
Form factor
Base Station
Manufactured
Between 2006 and 200x in Germany

Other features

Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-
RigReference ID
2953
MPN
HILBERLING-PT-008000A

Manuals, diagrams and brochures

Hilberling PT-8000A Block Diagram PDF - 216.5 kB, submitted by RigReference
Hilberling Pricelist 2018 PDF - 286.1 kB, submitted by RigReference
Hilberling PT-8000A Folder (EN/DE) PDF - 2.06 MB, submitted by RigReference
Hilberling PT-8000A Operating Manual PDF - 9.81 MB, submitted by RigReference

Upload relevant documents

Reviews

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Hilberling PT-8000A. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic price data, today's estimated value of the Hilberling PT-8000A in Good condition is around:

  • EUR 9,992

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2019 EUR 13290.00 New / Mint RigReference
