General characteristics

HAM bands
2m
Frequency stability
?
Tuning steps
12.5 / 25 kHz
Memories
10 channels in 1 bank(s)

Receiver

RX-range
144-146 MHz
Modulations
FM
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

TX-range
144-146 MHz
Modulations
FM
RF-output
High: 3-5 W (depending on voltage), Low: 0.5 W

Connections

Antenna
BNC
Impedance
50 Ω
Other
-

Electrical

Power requirements
5.5-16V DC
Current drain RX
Max 140 mA
TX
Max 1.2 A

Physical

Dimensions (w×h×d)
65 × 117 × 35 mm (2.56 × 4.61 × 1.38 in) without battery
Weight
495 gr (1.1 lbs) with BP-3
Form factor
Handheld
Manufactured
Between 1983 and 19xx

Other features

Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-
RigReference ID
2960
MPN
ICOM-IC-000002E
