The ICOM IC-12E is a handheld UHF transceiver. It covers 1260-1300 MHz for both transmit and receive. RF output power is selectable between High: 1 W and Low: 100 mW. The radio operates on 7.2-13.2V DC and weighs 610 gr with BP-3. Dimensions are 171 × 65 × 36 mm with BP-3. Current drain is 65-250 mA while receiving and a maximum of 900 mA while transmitting.
General characteristics
- HAM bands
- 23cm
- Frequency stability
- ?
- Tuning steps
- ?
- Memories
- ?
Receiver
- RX-range
- 1260-1300 MHz
- Modulations
- FM
- Sensitivity
- ?
- Selectivity
- ?
- Filters
- ?
- Receiver system
- ?
- IF-frequencies
- ?
- Image rejection
- ?
- Audio output
- ?
Transmitter
- TX-range
- 1260-1300 MHz
- Modulations
- FM
- RF-output
- High: 1 W, Low: 100 mW
Connections
- Antenna
- -
- Impedance
- 50Ω
- Other
- -
Electrical
- Power requirements
- 7.2-13.2V DC
- Current drain RX
- 65-250 mA
- TX
- Max 900 mA
Physical
- Dimensions (w×h×d)
- 65 × 171 × 36 mm (2.56 × 6.73 × 1.42 in) with BP-3
- Weight
- 610 gr (1.3 lbs) with BP-3
- Form factor
- Handheld
- Manufactured
- Between 1987 and 19xx
Other features
- Usage
- Amateur / Ham radio operators
- Features + options
- -
- Accessories
- -
- RigReference ID
- 2971
- MPN
- ICOM-IC-000012E
Manuals, diagrams and brochures
-
No documents available for this particular model.
- Upload relevant documents
New and second-hand prices
Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used ICOM IC-12E. Just bought or sold this model? Let us know what you traded it for and help other ham operators!
Based on similar Transceiver equipment, the estimated value of the ICOM IC-12E is around:
- USD 215 ~ USD 400
This estimate is based on similar equipment and may not reflect the exact value of this model.
These estimates are based on the following prices:
