This model was replaced by the ICOM IC-2410H.

General characteristics

HAM bands
2m  70cm
Frequency stability
?
Tuning steps
?
Memories
40 channels in 1 bank(s)

Receiver

RX-range
138-174 / 440-450 MHz
Modulations
AM   FM
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
Double conversion superheterodyne
IF-frequencies
?
Image rejection
?
Audio output
Internal speaker

Transmitter

TX-range
140-150 / 440-450 MHz
Modulations
FM
RF-output
High: 45/35 W, Low: 5/5 W

Connections

Antenna
SO-239
Impedance
50Ω
Other
-

Electrical

Power requirements
13.8 V DC
Current drain RX
?
TX
10.5 A max

Physical

Dimensions (w×h×d)
150 × 50 × 195 mm (5.91 × 1.97 × 7.68 in)
Weight
?
Form factor
Mobile
Manufactured
Between 198x and 19xx in Japan

Other features

Usage
Amateur / Ham radio operators
Features + options
Twin RX
Dual Band Receive
CTCSS Tone Encode
Sub Band Mute
Two Call Channels
Dimmer
Priority Watch
Auto Repeater Function
Scan Functions
Remote Hand Mic
Accessories
-
RigReference ID
3006
MPN
ICOM-IC-002400A

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used ICOM IC-2400A. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the ICOM IC-2400A is around:

  • USD 99.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2019 USD 100.00 Used / Good Ashy Asher
