This model was replaced by the ICOM IC-2410H.

General characteristics

HAM bands
2m  70cm
Frequency stability
?
Tuning steps
?
Memories
40 channels in 1 bank(s)

Receiver

RX-range
138-174 / 440-450 MHz
Modulations
AM   FM
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
Double conversion superheterodyne
IF-frequencies
?
Image rejection
?
Audio output
Internal speaker

Transmitter

TX-range
140-150 / 440-450 MHz
Modulations
FM
RF-output
High: 45/35 W, Low: 5/5 W

Connections

Antenna
SO-239
Impedance
50Ω
Other
-

Electrical

Power requirements
13.8 V DC
Current drain RX
?
TX
10.5 A max

Physical

Dimensions (w×h×d)
150 × 50 × 195 mm (5.91 × 1.97 × 7.68 in)
Weight
?
Form factor
Mobile
Manufactured
Between 198x and 19xx in Japan

Other features

Usage
Amateur / Ham radio operators
Features + options
Twin RX
Dual Band Receive
CTCSS Tone Encode
Sub Band Mute
Two Call Channels
Dimmer
Priority Watch
Auto Repeater Function
Scan Functions
Remote Hand Mic
Accessories
-
RigReference ID
3006
MPN
ICOM-IC-002400A

Manuals, diagrams and brochures

Icom IC-2400AE IC 2500AE Instruction Manual.PDF 5DA020FC2DDBE7.42310460 PDF - 4.76 MB, submitted by KR

Upload relevant documents

Reviews

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used ICOM IC-2400A. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic price data, today's estimated value of the ICOM IC-2400A in Good condition is around:

  • USD 100

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2019 USD 100.00 Used / Good Ashy Asher
