Frequency range

RX-range
144-146 MHz (Europe)
143.8-148.2 MHz (USA)
TX-range
144-146 MHz (Europe)
143.8-148.2 MHz (USA)
HAM bands
?
Stability
?
Tuning steps
5 / 15 kHz
Filters
?

Receiver

Modulations
FM
Sensitivity
Better than 0.6 µV for 20 dB noise quieting
Selectivity
15 kHz (-6 dB), 30 kHz (-60 dB)
Receiver system
?
IF-frequencies
?
Image rejection
>60 dB
Audio output
?

Transmitter

Modulations
FM
RF-Output
High: 45 W, Low: 2 W

Connections

Antenna
SO-239
Impedance
50 Ω

Electrical

Power requirements
13.8V DC
Current drain RX
600-750 mA
TX
2.7-9.5 A

Physical

Dimensions (w×h×d)
140 × 50 × 222 mm (5.51 × 1.97 × 8.74 in)
Weight
1.90 kg (4.2 lbs)
Form factor
Unknown
Manufactured
Between 1983 and 19xx in Japan
MPN
ICOM-IC-000025H

Other features

Memories
5 channels in 1 bank(s)
Usage
Amateur / Ham radio operators
Features + options
?
Accessories
?

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Show other documents.
Find the ICOM IC-25H user manuals on eBay #ad

Reviews & stories

IC-25H Still going strong!

ICOM IC-25H, VHF Transceiver

Picked up and IC-25H used in 1996. Became my first 2m rig and performed will for me for several years. Passed it on to my son in 2000 and he's still running it nearly every evening on packet. Simple radio, no tone board, but it did a great job for me on 2m simplex and now running packet for my son. No doubt we've gotten our monies worth from this radio. Built extremely well and just keeps going. Very quiet front end, no interference ever on that radio. The newer radios I purchased to replace it were inferior in selectivity and adjacent channel rejection.. Very little is built like this for 2m today. The only radio I've owned that seemed as quiet and selective is my FT-736R, but it's a totally different class of radio.

73 Dave Koester KC0BCZ

Written by kc0bcz on May 24, 2018

Overall

Performance
Build quality
Features
User friendlyness
Value for money
Aquired
Mint condition in 2018

What's it worth

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the current value of the ICOM IC-25H. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's value of the ICOM IC-25H might be around:

  • USD 34.00
Year Historic price Condition Submitted by
2016 USD 35.00 Used / Good RigReference
