General characteristics

HAM bands
160m  80m  40m  30m (WARC)  20m  17m (WARC)  15m  12m (WARC)  6m  10m
Frequency stability
?
Tuning steps
?
Memories
?

Receiver

RX-range
10-160 m + WARC/50-54 MHz
Modulations
AM   FM   CW   SSB
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

TX-range
10-160 m + WARC/50-54 MHz
Modulations
AM   FM   CW   SSB
RF-output
100 / 100 W

Connections

Antenna
SO-239
Impedance
50 Ω
Other
-

Electrical

Power requirements
Mains
Current drain RX
?
TX
?

Physical

Dimensions (w×h×d)
330.2 × 111.76 × 284.48 mm (13.00 × 4.40 × 11.20 in)
Weight
10.48 kg (23.1 lbs)
Form factor
Base Station
Manufactured
Between 19xx and 19xx

Other features

Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-
RigReference ID
3146
MPN
ICOM-IC-000736

Manuals, diagrams and brochures

IC-736 IC 738 User Manual PDF - 7.32 MB, submitted by Ian
IC-736 IC 738 Service Manual PDF - 8.08 MB, submitted by Ian
IC-736 IC 738 Review 1995 PDF - 1.09 MB, submitted by Ian

Upload relevant documents

Reviews & stories

Rating Title Submitted
Great Radio! 13 years ago by kd-5-bgt

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used ICOM IC-736. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the ICOM IC-736 is around:

  • USD 96.00
  • GBP 180.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2019 GBP 200.00 Used / Good John G8CCD
2019 GBP 200.00 Used / Mint John
2010 USD 600.00 Used / Mint kd-5-bgt
