General characteristics

HAM bands
160m  80m  40m  30m (WARC)  20m  17m (WARC)  15m  12m (WARC)  6m  10m
Frequency stability
?
Tuning steps
?
Memories
?

Receiver

RX-range
10-160 m + WARC/6 m
Modulations
AM   FM   CW   SSB
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

TX-range
10-160 m + WARC/6 m
Modulations
AM   FM   CW   SSB
RF-output
5-100/5-100 W (5-40/5-40 W AM)

Connections

Antenna
SO-239
Impedance
50 Ω
Other
-

Electrical

Power requirements
13.8V DC
Current drain RX
?
TX
?

Physical

Dimensions (w×h×d)
340 × 111 × 285 mm (13.39 × 4.37 × 11.22 in)
Weight
9.30 kg (20.5 lbs)
Form factor
Base Station
Manufactured
Between 19xx and 19xx

Other features

Usage
Amateur / Ham radio operators
Features + options
DSP, Twin RX
Accessories
-
RigReference ID
3160
MPN
ICOM-IC-000756

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Reviews & stories

Rating Title Submitted
Great Rig, bad display... 9 years ago by WB4IUY

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used ICOM IC-756. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the ICOM IC-756 is around:

  • USD 89.00 ~ USD 213.00
  • GBP 273.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2011 GBP 550.00 Used / Good m6wsb
2008 USD 850.00 Used / Good KD7TXO
2002 USD 1200.00 Used / Good K4XXX
1995 USD 2500.00 New / Mint WB4IUY
