General characteristics

HAM bands
2m  70cm
Frequency stability
?
Tuning steps
?
Memories
100 channels in 1 bank(s)

Receiver

RX-range
136-174 / 400-470 MHz
Modulations
FM
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

TX-range
144-148 / 440-450 MHz
Modulations
FM
RF-output
High: 5/5 W, Medium: 0.5/0.5 W, Low: 15/15 mW

Connections

Antenna
-
Impedance
50 Ω
Other
-

Electrical

Power requirements
4.8-9.6V DC with battery pack or 4.5-16V DC external
Current drain RX
30-170 mA
TX
Max 1.6 A

Physical

Dimensions (w×h×d)
57 × 125 × 31 mm (2.24 × 4.92 × 1.22 in)
Weight
340 gr (12.0 oz) with BP-171
Form factor
Unknown
Manufactured
Between 1995 and 199x in Japan

Other features

Usage
Amateur / Ham radio operators
Features + options
CTCSS, DTMF. Twin RX
Accessories
-
RigReference ID
3265
MPN
ICOM-IC-W000031A
