General characteristics

HAM bands
?
Frequency stability
?
Tuning steps
?

Receiver

RX-range
136-175 / 300-524 / 800-1300 MHz (Cellular blocked)
Modulations
AM   FM
Sensitivity
0.16 µV (12 dB SINAD)
Selectivity
12 kHz (-6 dB), 28 kHz (-40 dB)
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

TX-range
144-148 / 438-450 MHz
Modulations
FM
RF-Output
High: 50/35 W, Medium: 10/10 W, Low: 5/5 W

Connections

Antenna
N-type
Impedance
50 Ω
Other
-

Electrical

Power requirements
13.8V DC
Current drain RX
Max 1 A
TX
4-11.5 A

Physical

Manufactured
Between 2002 and 200x
Dimensions (w×h×d)
?
Weight
1.40 kg (3.1 lbs)
Form factor
Unknown

Other features

Memories
200 channels in 1 bank(s)
Usage
Amateur / Ham radio operators
Features + options
Alpha tags. CTCSS/DTSS. Twin RX
Accessories
?
MPN
KENWOOD-TM-V000708A
