General characteristics

HAM bands
2m
Frequency stability
?
Tuning steps
?
Memories
12 channels in 1 bank(s)

Receiver

RX-range
144-146 MHz
Modulations
FM
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
XTAL
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

TX-range
144-146 MHz
Modulations
FM
RF-output
2 W

Connections

Antenna
Built-in sweep
Impedance
50 Ω
Other
-

Electrical

Power requirements
9.6-15.6V DC
Current drain RX
45 mA
TX
Max 700 mA

Physical

Dimensions (w×h×d)
135 × 58 × 191 mm (5.31 × 2.28 × 7.52 in)
Weight
1.60 kg (3.5 lbs) 10×NiCd and mic included
Form factor
Portable
Manufactured
Between 197x and 19xx in Japan

Other features

Usage
Amateur / Ham radio operators
Features + options
1750 Hz tone burst
VFO option.
Accessories
-
RigReference ID
3444
MPN
KENWOOD-TR-002200GX

Manuals, diagrams and brochures

Kenwood TR-2200 Instruction Manual PDF - Unknown size, submitted by RigReference

Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Kenwood TR-2200GX. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Kenwood TR-2200GX is around:

  • GBP 1.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
1980 GBP 100.00 Used / Good nigeljcoote
