General characteristics

HAM bands
160m  80m  40m  30m (WARC)  20m  17m (WARC)  15m  12m (WARC)  6m  10m
Frequency stability
?
Tuning steps
?
Memories
?

Receiver

RX-range
0.5-30 MHz / 50-54 MHz
Modulations
AM   FM   CW   SSB
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

TX-range
10-160 m + WARC / 50-54 MHz
Modulations
AM   FM   CW   SSB
RF-output
Max 100/100 W

Connections

Antenna
SO-239
Impedance
50 Ω
Other
-

Electrical

Power requirements
13.8V DC
Current drain RX
?
TX
?

Physical

Dimensions (w×h×d)
270 × 96 × 271 mm (10.63 × 3.78 × 10.67 in)
Weight
?
Form factor
Base Station
Manufactured
Between 19xx and 19xx

Other features

Usage
Amateur / Ham radio operators
Features + options
DSP
Accessories
-
RigReference ID
3494
MPN
KENWOOD-TS-000570S

Manuals, diagrams and brochures

Kenwood TS-570D/S/G Instruction Manual PDF - Unknown size, submitted by RigReference
Kenwood TS-570 Service Manual (A4) PDF - Unknown size, submitted by RigReference

Upload relevant documents

Reviews & stories

Rating Title Submitted
Another Great Kenwood 7 years ago by KA9MOT
Excellent Radio 8 years ago by k5fs

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Kenwood TS-570S. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Kenwood TS-570S is around:

  • USD 125.00 ~ USD 303.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2012 USD 500.00 Used / Good KA9MOT
2007 USD 625.00 Used / Good k5fs
1998 USD 675.00 New / Mint Marc
