The Lowe HF-225 follows on the success of the Lowe HF-125, and has been designed specifically to fulfil the requirements of the dedicated shortwave listener or DX enthusiast. Its ability to perform on a crowded band with strong adjacent stations is one of its major strengths. The HF-225 is easy to use with controls being simple and sensible. Continuous coverage from 30 kHz to 30 MHz is provided in AM, USB, LSB and CW modes. The optional D-225 adds FM narrow mode and synchronous AM. Unlike other receivers the HF-225 comes complete with a comprehensive range of bandwidths: 2.2 kHz for SSB (and AM ECSS), 4, 7 and 10 kHz for AM reception. A 200 Hz audio filter is included for the CW listener. Tuning is accomplished through the use of 1 MHz UP/DOWN buttons and a multi-speed main tuning knob with recessed finger hole. Direct frequency entry is available with the optional KPAD-1 keypad controller. Thirty memories store your favorite stations. Antenna jacks are provided for either a PL-259 (50 ohm) or single wire (600 ohm). Jacks are provided for headphones, record out, speaker, 12V DC power and optional keypad. The Lowe HF-225 provides elegant simplicity without sacrificing performance.
The Lowe HF-225E is an enhanced version of the HF-225.
General characteristics
- HAM bands
- ?
- Frequency stability
- < ±30 Hz in 1 hour typical
- Tuning steps
- 8 Hz / 0.05 kHz
- Memories
- 30 channels in 1 bank(s)
Receiver
- RX-range
- 0.03-30 MHz
- Modulations
- AM AM-sync N-FM CW USB LSB
- Sensitivity
- 0.5 µV SSB 2-30 Mhz
- Selectivity
- 2.2 kHz 2.3 kHz -6 dB
4.0 kHz 5.9 kHz -6 dB
7.0 kHz 8.8 kHz -6 dB
10 kHz 10.5 kHz -6 dB - Filters
- ?
- Receiver system
- Double conversion superheterodyne
- IF-frequencies
- 1st: 45 MHz
2nd: 455 kHz - Image rejection
- ?
- Audio output
- 1.6W 8 ohms 5% THD
Connections
- Antenna
- SO-239 + Hi-Z
- Impedance
- 50 Ω
- Other
- -
Electrical
- Power requirements
- 12V DC or internal batteries
- Current drain RX
- ?
- TX
- -
Physical
- Dimensions (w×h×d)
- 253 × 109 × 204 mm (9.96 × 4.29 × 8.03 in)
- Weight
- 1.90 kg (4.2 lbs)
- Form factor
- Mobile
- Manufactured
- Between 1990 and 1998 in Great Britain
Other features
- Usage
- Amateur / Ham radio operators
- Features + options
- -
- Accessories
- -
- RigReference ID
- 3557
- MPN
- LOWE-HF-000225
Manuals, diagrams and brochures
- Lowe HF-225 User Manual PDF - 2.09 MB, submitted by Gerd
- Lowe HF-225 Service Manual PDF - 4.61 MB, submitted by Gerd
- Upload relevant documents
New and second-hand prices
Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Lowe HF-225. Just bought or sold this model? Let us know what you traded it for and help other ham operators!
Based on similar Receiver equipment, the estimated value of the Lowe HF-225 is around:
- USD 265 ~ USD 492
This estimate is based on similar equipment and may not reflect the exact value of this model.
