General characteristics

HAM bands
?
Frequency stability
?
Tuning steps
1 / 10 / 100 kHz
Memories
?

Receiver

RX-range
28-29.7 MHz (25.150-29.7 after modification)
Modulations
AM   FM   SSB
Sensitivity
0.5 µV (10 dB S/N)
Selectivity
?
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
>70 dB
Audio output
?

Transmitter

TX-range
28-29.7 MHz (25.150-29.7 after modification)
Modulations
AM   FM   SSB
RF-output
AM: 7 W, FM/SSB: 25 W

Connections

Antenna
SO-239
Impedance
50 Ω
Other
-

Electrical

Power requirements
12-16V DC
Current drain RX
?
TX
3-5 A

Physical

Dimensions (w×h×d)
154 × 52 × 248 mm (6.06 × 2.05 × 9.76 in)
Weight
1.50 kg (3.3 lbs)
Form factor
Mobile
Manufactured
Between 199x and 200x

Other features

Usage
Amateur / Ham radio operators
Features + options
Repeater offset (Shift)
Accessories
-
RigReference ID
3768
MPN
RADIOSHACK-/-REALISTIC-HTX-000010

Manuals, diagrams and brochures

Radioshack HTX-10 Owner's Manual PDF - 2.05 MB, submitted by Gerd
Radioshack HtX-10 Service Manual PDF - 2.88 MB, submitted by Gerd

Upload relevant documents

Reviews & stories

Rating Title Submitted
Dx ing 4 weeks ago by Gerd
HTX-10 8 years ago by deadgoose

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used RadioShack / Realistic HTX-10. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the RadioShack / Realistic HTX-10 is around:

  • EUR 39.00
  • USD 19.00 ~ USD 5.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2020 EUR 40.00 Used / Good Gerd
2014 USD 50.00 Used / Okay ac9hp
2010 USD 50.00 Used / Mint deadgoose
2009 USD 75.00 Used / Good KC2UGV
2004 USD 50.00 New / Mint N6OTQ
