RadioShack / Realistic Pro-95

Handheld HF/VHF/UHF Scanner / receiver

Add a review Add to my shack


Login or Register to upload images

New price 2002 in the US: $249.95

General characteristics

HAM bands
6m  2m  1.25m  70cm  33cm  23cm  10m
Frequency stability
?
Tuning steps
5 / 6.25 / 10 / 12.5 kHz
Memories
1000 channels in 10 bank(s) @ 60 channels/second

Receiver

RX-range
25-54 / 108-174 / 216-225 / 406-512 / 806-824 / 851-869
896-960 /1240-1300 MHz
Modulations
AM   FM
Sensitivity
FM
25–54 MHz: 0.3 μV
108–136.9875 MHz: 0.3 μV
137–174 MHz: 0.5 μV
216–225 MHz: 0.5 μV
406–512 MHz: 0.5 μV
806–960 MHz: 0.7 μV
1240–1300 MHz: 0.7 μV
AM
25–54 MHz: 1 μV
108–136.9875 MHz: 1 μV
137–174 MHz: 1.5 μV
216–225 MHz: 1.5 μV
406–512 MHz: 2 μV
806–960 MHz: 2 μV
1240–1300 MHz: 3 μV
Selectivity
25–27.995 MHz (AM)
±5 kHz (-6 dB)
±6 kHz (-50 dB)

All other frequencies (AM and FM)
±10 kHz (-6 dB)
±18 kHz (-50 dB)
Filters
?
Receiver system
Triple conversion superheterodyne
IF-frequencies
1st: 380.8 MHz
2nd: 21.4 MHz
3rd: 455 kHz
Image rejection
380.8 MHz at 154.1 MHz: 60 dB21.4 MHz at 154.1 MHz: 100 dB
Audio output
170 mW (8 ohm, 10% THD)

Connections

Antenna
BNC
Impedance
50Ω
Other
-

Electrical

Power requirements
Internal: 4.8-6 V DC (4×R6 / AA)External: 9 V DC
Current drain RX
90~150 mA
TX
-

Physical

Dimensions (w×h×d)
62 × 157 × 41 mm (2.44 × 6.18 × 1.61 in)
Weight
240 gr (8.5 oz) without antenna and batteries
Form factor
Handheld
Manufactured
Between 2002 and 200x

Other features

Usage
Amateur / Ham radio operators
Features + options
Alpha tags
Weather alert
Dual trunking
Accessories
-
RigReference ID
3818
MPN
RADIOSHACK-REALISTIC-PRO-000095

Manuals, diagrams and brochures

RadioShack PRO-95 Owner's Manual PDF - 1.41 MB, submitted by Gerd

Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used RadioShack / Realistic Pro-95. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the RadioShack / Realistic Pro-95 is around:

  • USD 12.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2003 USD 140.00 New / Mint ab2rc
