General characteristics

HAM bands
10m
Frequency stability
?
Tuning steps
?
Memories
?

Receiver

RX-range
28-29.7 MHz
Modulations
CW   SSB
Sensitivity
0.25 µV (10 dB S/N)
Selectivity
?
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
65 dB
Audio output
?

Transmitter

TX-range
28-29.7 MHz
Modulations
CW   SSB
RF-output
High: 25 W, Low: 5 W

Connections

Antenna
SO-239
Impedance
50Ω
Other
-

Electrical

Power requirements
13.8V DC +/- 15 %
Current drain RX
0.5-1 A
TX
Max 6 A

Physical

Dimensions (w×h×d)
185 × 62 × 200 mm (7.28 × 2.44 × 7.87 in)
Weight
1.90 kg (4.2 lbs)
Form factor
Mobile
Manufactured
Between 1988 and 199x in Japan

Other features

Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-
RigReference ID
3830
MPN
RADIOSHACK-REALISTIC-HTX-000100

Manuals, diagrams and brochures

Radioshack HTX-100 Owner's Manual PDF - 1.16 MB, submitted by Gerd

Upload relevant documents

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used RadioShack / Realistic HTX-100. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the RadioShack / Realistic HTX-100 is around:

  • USD 71.00 ~ USD 94.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2020 USD 95.00 Used / Fair Scott Bridges
2013 USD 100.00 Used / Fair ac9hp
1988 USD 179.00 New / Mint N6OTQ
