General characteristics

HAM bands
2m
Frequency stability
?
Tuning steps
5 / 10 / 12.5 / 20 / 25 / 50 kHz
Memories
40 channels in 1 bank(s)

Receiver

RX-range
144-146 MHz (138-174 MHz)
Modulations
FM
Sensitivity
0.16 µV (12 dB SINAD)
Selectivity
?
Filters
?
Receiver system
? conversion superheterodyne
IF-frequencies
?
Image rejection
>60 dB
Audio output
?

Transmitter

TX-range
144-146 MHz (138-174 MHz)
Modulations
FM
RF-output
High: 5 W, Medium: 2.5 W, Low: 350 mW

Connections

Antenna
BNC
Impedance
50 Ω
Other
-

Electrical

Power requirements
7.2V DC (battery), 5-16V DC (external)
Current drain RX
13/35 mA (save/stby)
TX
Max 950 mA

Physical

Dimensions (w×h×d)
55 × 84 × 31 mm (2.17 × 3.31 × 1.22 in)
Weight
185 gr (6.5 oz)
Form factor
Handheld
Manufactured
Between xxxx and xxxx

Other features

Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-
RigReference ID
3990
MPN
SOMMERKAMP-TS-000277DX
