This rig shares circuitry with the FT-277 and FT-101

General characteristics

HAM bands
160m  80m  40m  20m  15m  10m
Frequency stability
?
Tuning steps
?
Memories
24 channels in 1 bank(s)

Receiver

RX-range
10-160m / 10-10.5 MHz (WWV)
26.965-27.255 MHz
Modulations
CW   SSB
Sensitivity
AM: 2 µV (10 dB S/N)
SSB/CW: 0.5 µV (10 dB S/N)
Selectivity
AM/SSB: 2.4 kHz (-6 dB), 4.4 kHz (-60 dB)
CW (option): 600 Hz (-6 dB), 1.2 kHz (-60 dB)
Filters
?
Receiver system
X-TAL
IF-frequencies
?
Image rejection
>50 dB
Audio output
?

Transmitter

TX-range
10-160m / 10-10.5 MHz (WWV)
26.965-27.255 MHz
Modulations
CW   SSB
RF-output
AM: 80 W (input), 50% duty cycle (slightly lower on 10m), SSB: 260 W (PEP input), CW: 180 W (input)

Connections

Antenna
SO-239
Impedance
50/75 Ω
Other
-

Electrical

Power requirements
13.8V DC or mains
Current drain RX
0.5 A
TX
Max 21 A

Physical

Dimensions (w×h×d)
340 × 153 × 285 mm (13.39 × 6.02 × 11.22 in)
Weight
15.00 kg (33.1 lbs)
Form factor
Base Station
Manufactured
Between 1972 and 1974 in Japan

Other features

Usage
Amateur / Ham radio operators
Features + options
27.265-27.555 MHz XTAL option, RX and TX.
Accessories
-
RigReference ID
3994
MPN
SOMMERKAMP-TS-000288A/24CH

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Reviews

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Sommerkamp TS-288A/24CH. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on similar Transceiver equipment, the estimated value of the Sommerkamp TS-288A/24CH is around:

  • USD 132 ~ USD 246

This estimate is based on similar equipment and may not reflect the exact value of this model.

These estimates are based on the following prices:
