General characteristics

HAM bands
160m  80m  60m  40m  30m (WARC)  20m  17m (WARC)  15m  12m (WARC)  11m (CB)  10m
Frequency stability
?
Tuning steps
0.1 kHz
Memories
None

Receiver

RX-range
0.01-30 MHz + FM broadcast band
Modulations
AM   CW   USB   LSB
Sensitivity
AM < 1 µV
SSB < 0,3 µV
Selectivity
AM
10 kHz (-6 dB), 16 kHz (-60 dB)
4,4 (-6 dB), 8 kHz (-60 dB)
SSB
2,0 (-6 dB), 3,4 kHz (-60 dB)
Filters
?
Receiver system
Double conversion superheterodyne
IF-frequencies
1st: 55.845 MHz
2nd: 455 kHz
Image rejection
?
Audio output
?

Connections

Antenna
Built-in sweep
Impedance
?
Other
-

Electrical

Power requirements
12 V DC external, 8 x R20 + 2 x R6 batteries or mains
Current drain RX
?
TX
-

Physical

Dimensions (w×h×d)
254 × 102 × 335 mm (10.00 × 4.02 × 13.19 in)
Weight
7.71 kg (17.0 lbs)
Form factor
Base Station
Manufactured
Between 1981 and 1986 in Japan

Other features

Usage
Amateur / Ham radio operators
Features + options
S/Battery-Meter
Record Jack
Pre-selector
NB
Dial Lamp
Dial Lamp Switch
Carry Handle
Muting
RF Gain
Accessories
-
RigReference ID
4003
MPN
SONY-CRF-000001
