6LQ6 final

General characteristics

HAM bands
80m  40m  20m  15m  10m
Frequency stability
?
Tuning steps
Continuous
Memories
None

Receiver

RX-range
10-80 m
3.5-4 / 7-7.3 / 14-14.35 / 21-21.45 / 28-29.7 MHz
Modulations
CW   SSB
Sensitivity
0.5 µV (10 S/N)
Selectivity
?
Filters
?
Receiver system
? conversion superheterodyne
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

TX-range
10-80 m
3.5-4 / 7-7.3 / 14-14.35 / 21-21.45 / 28-29.7 MHz
Modulations
CW   SSB
RF-output
SSB: 260 W (PEP input), CW: 180 W (input)

Connections

Antenna
SO-239
Impedance
50/75Ω
Other
-

Electrical

Power requirements
Mains
Current drain RX
?
TX
?

Physical

Dimensions (w×h×d)
?
Weight
?
Form factor
Base Station
Manufactured
Between 1969 and 19xx

Other features

Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-
RigReference ID
4115
MPN
SWAN-(CUBIC)-000260-CYGNET
