New price in 1970: USD 550.- / DM 2450.-

General characteristics

HAM bands
80m  40m  20m  15m  10m
Frequency stability
?
Tuning steps
Continuous
Memories
None

Receiver

RX-range
10-80m
Modulations
CW   USB   LSB
Sensitivity
0.5 µV @ 10 dB S+S/N
Selectivity
2.1 kHz @ 6 dB (1.8:1 shape factor)
Filters
9MHz crystal
Receiver system
Superheterodyne
IF-frequencies
?
Image rejection
?
Audio output
External speaker required

Transmitter

TX-range
10-80m
Modulations
CW   USB   LSB
RF-output
SSB: 550 W PEP, CW: 360 W

Connections

Antenna
SO-239
Impedance
50Ω
Other
-

Electrical

Power requirements
Mains via CS550 Power Supplier / Speaker unit
Current drain RX
?
TX
?

Physical

Dimensions (w×h×d)
152 × 280 × 330 mm (5.98 × 11.02 × 12.99 in)
Weight
7.70 kg (17.0 lbs)
Form factor
Base Station
Manufactured
Between 1969 and 19xx in USA

Other features

Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-
RigReference ID
4532
MPN
GALAXY-GT000550

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Reviews & stories

Rating Title Submitted
I agree with the other review 4 years ago by marshallandlawanda
Outstanding Transceiver 10 years ago by john.w3ik

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Galaxy GT550. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Galaxy GT550 is around:

  • USD 262.00 ~ USD 2.00
  • DEM 30.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2020 USD 275.00 Used / Good eBay
1980 USD 190.00 New / Mint marshallandlawanda
1970 USD 550.00 New / Mint RigReference
1970 DEM 2450.00 New / Mint RigReference
