General characteristics

HAM bands
160m  80m  40m  30m (WARC)  20m  17m (WARC)  15m  12m (WARC)  10m
Frequency stability
?
Tuning steps
?
Memories
?

Receiver

RX-range
10-160 m + WARC
Modulations
CW   USB   LSB
Sensitivity
0.3 µV (10 dB S+N/N)
Selectivity
?
Filters
2.4 kHz (300/500 Hz optional) + audio filters
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

TX-range
10-160 m + WARC
Modulations
CW   USB   LSB
RF-output
200 W

Connections

Antenna
-
Impedance
50 Ω
Other
-

Electrical

Power requirements
12V DC
Current drain RX
?
TX
?

Physical

Dimensions (w×h×d)
295 × 120 × 381 mm (11.61 × 4.72 × 15.00 in)
Weight
5.60 kg (12.4 lbs)
Form factor
Mobile
Manufactured
Between 1980 and 1982

Other features

Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-
RigReference ID
4166
MPN
TEN-TEC-DELTA-(000580)

Manuals, diagrams and brochures

Ten-Tec 580 Delta Operator's Manual PDF - 7.38 MB, submitted by Gerd

Upload relevant documents

Reviews & stories

Rating Title Submitted
Ten-Tec Delta 580 HF Transceiver 10 years ago by N4UED

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Ten-Tec Delta (580). Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Ten-Tec Delta (580) is around:

  • USD 43.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2008 USD 175.00 Used / Good N4UED
