General characteristics

HAM bands
160m  80m  40m  30m (WARC)  20m  17m (WARC)  15m  12m (WARC)  6m  2m  70cm  10m
Frequency stability
?
Tuning steps
?
Memories
?

Receiver

RX-range
10-160 m + WARC / 50-54 / 144-146 / 430-440 MHz
Modulations
AM   FM   CW   SSB
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

TX-range
10-160 m + WARC / 50-54 / 144-146 / 430-440 MHz
Modulations
AM   FM   CW   SSB
RF-output
100/100/50/20 W (25/25/12.5/5 W AM)

Connections

Antenna
-
Impedance
50 Ω
Other
-

Electrical

Power requirements
13.8V DC
Current drain RX
Max 1.6 A
TX
Max 22 A

Physical

Dimensions (w×h×d)
160 × 54 × 205 mm (6.30 × 2.13 × 8.07 in)
Weight
3.00 kg (6.6 lbs)
Form factor
Mobile
Manufactured
Between 2000 and 200x

Other features

Usage
Amateur / Ham radio operators
Features + options
DSP, CTCSS
Accessories
-
RigReference ID
4230
MPN
YAESU-FT-000100D

Manuals, diagrams and brochures

Yaesu FT-100D Operating Manual PDF - Unknown size, submitted by RigReference

Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Yaesu FT-100D. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Yaesu FT-100D is around:

  • USD 369.00 ~ USD 191.00
  • CAD 824.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2024 CAD 825.00 Used / Good Cathy Johnson
2020 USD 200.00 New / Mint Paul Terry Walhus
2018 USD 450.00 Used / Good Ivan Taylor
2017 USD 500.00 Used / Good Rodgerzk
2014 USD 500.00 Used / Good ke3oxmsd
