General characteristics

HAM bands
6m  2m  70cm
Frequency stability
?
Tuning steps
?
Memories
?

Receiver

RX-range
2m (6m and 70cm optional)
Modulations
FM   CW   SSB
Sensitivity
FM: <0.25 µV (12 dB SINAD)
SSB: <0.15 µV (10 dB (S+N)/N)
Selectivity
FM: 15 kHz (-6 dB), 30 kHz (-60 dB)
SSB: 2.4 kHz (-6 dB), 4.0 kHz (-60 dB)
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
Better than 60 dB
Audio output
?

Transmitter

TX-range
2m (6m and 70cm optional)
Modulations
FM   CW   SSB
RF-output
10 W

Connections

Antenna
SO-239
Impedance
50Ω
Other
-

Electrical

Power requirements
13.8V DC or mains
Current drain RX
1.5 A
TX
Max 4.5 A

Physical

Dimensions (w×h×d)
334 × 129 × 315 mm (13.15 × 5.08 × 12.40 in)
Weight
11.00 kg (24.3 lbs) without options
Form factor
Base Station
Manufactured
Between 1983 and 19xx

Other features

Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-
RigReference ID
4330
MPN
YAESU-FT-000726R

Manuals, diagrams and brochures

Yaesu FT-726R Operating Manual PDF - Unknown size, submitted by RigReference
Yaesu FT-726R Service Manual PDF - Unknown size, submitted by RigReference

Upload relevant documents

Reviews & stories

Rating Title Submitted
First love ... 4 ever. 8 years ago by Hugo26

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Yaesu FT-726R. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Yaesu FT-726R is around:

  • EUR 199.00
  • GBP 122.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2017 GBP 125.00 Used / Okay John G8CCD
2010 EUR 500.00 Used / Good Hugo26
