General characteristics

HAM bands
?
Frequency stability
10 ppm (0 to 60 C)
Tuning steps
1 Hz kHz
Memories
?

Receiver

RX-range
9 kHz - 1800 MHz (3500 MHz with optional downconverter)
Modulations
AM   N-AM   AM-sync   FM   N-FM   W-FM   CW   USB   LSB   DSB   ISB   APCO-25
Sensitivity
Mode 0.15-500 MHz 500-1800 MHz
AM, AMS 1.7V 1.85V
LSB, USB 0.35V 0.37V
CW 0.2V 0.25V
FM3, FM6, FMN 0.7V 0.8V
FMW (optional) 2.0V 2.0V
Selectivity
AM 6 kHz
AMN 4 kHz
AMS 4 kHz
LSB, USB 2.5 kHz
CW 500 Hz
FM3 3 kHz
FM6 6 kHz
FMN 12 kHz
FMW (optional) 230 kHz
Filters
?
Receiver system
DDS-based double-conversion superheterodyne with software-defined last IF stage and demodulator
IF-frequencies
1st: 109.65 MHz
2nd: 12 kHz
Image rejection
60 dB
Audio output
?

Connections

Antenna
SMA
Impedance
50Ω
Other
-

Electrical

Power requirements
Draws from PCI interface
Current drain RX
?
TX
-

Physical

Dimensions (w×h×d)
195 × 99 × 19 mm (7.68 × 3.90 × 0.75 in)
Weight
310 gr (10.9 oz)
Form factor
PC-card
Manufactured
Between 200x and 200x

Other features

Usage
Amateur / Ham radio operators
Features + options
DSP
Trunking option
12 kHz IF2 output
Number of memory channels limited by computer memory
Accessories
-
RigReference ID
4427
MPN
WINRADIO-WR-G000305I
