The Perseus SDR requires a computer with a 2GHz Intel Pentium CPU (or compatible) and 1GB RAM.
General characteristics
- HAM bands
- 160m 80m 60m 40m 30m (WARC) 20m 17m (WARC) 15m 12m (WARC) 11m (CB) 10m 2000m
- Frequency stability
- ±1 ppm after calibration
- Tuning steps
- ?
- Memories
- ?
Receiver
- RX-range
- 0.01-30 MHz
- Modulations
- AM AM-sync N-FM CW USB LSB
- Sensitivity
- 0.49 µV (SSB, S+N/N=10 dB, Preamp ON, Dither OFF)
- Selectivity
- Software Defined (>100 dB Stop Band Attenuation)
- Filters
- 0-1.7, 1.7-2.1, 2.1-3.0, 3.0-4.2, 4.2-6.0, 6.0-8.4, 8.4-12.0, 12-17, 17-24, 24-32 or OFF (0-40 MHz Wide-Band Mode)
- Receiver system
- DSP
- IF-frequencies
- ?
- Image rejection
- 90 dB
- Audio output
- ?
Connections
- Antenna
- BNC
- Impedance
- 50Ω
- Other
- -
Electrical
- Power requirements
- 5V DC
- Current drain RX
- 700 mA
- TX
- -
Physical
- Dimensions (w×h×d)
- 110 × 36 × 185 mm (4.33 × 1.42 × 7.28 in)
- Weight
- 380 gr (13.4 oz)
- Form factor
- Headless
- Manufactured
- Between 2007 and 20xx in Italy
Other features
- Usage
- Amateur / Ham radio operators
- Features + options
- USB 2.0 interface
- Accessories
- -
- RigReference ID
- 5008
- MPN
- PERSEUS-SDR
Manuals, diagrams and brochures
- Perseus User Manual PDF - 2.94 MB, submitted by RigReference
- Perseus CI-V Interface Reference Manual PDF - 309.0 kB, submitted by RigReference
- Upload relevant documents
New and second-hand prices
Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Perseus SDR. Just bought or sold this model? Let us know what you traded it for and help other ham operators!
Based on historic data, today's second-hand price of the Perseus SDR is around:
- EUR 205.00
- USD 172.00
These estimates are based on the following prices:
