Expert Electronics ColibriDDC Compact dual-channel SDR receiver

 (0.0/5)  Add a story   View all stories (0)   Add to my shack



Login or Register to upload images

Compact, high quality HF receiver. Requires a PC to operate (Windows / Linux)

Price when new: EUR 660.-

Frequency range

RX-range
0.01-55 MHz (800 MHz with oversampling)
TX-range
-
HAM bands
160m  80m  60m  40m  30m (WARC)  20m  17m (WARC)  15m  12m (WARC)  11m (CB)  6m  10m
Stability
+/- 0.5 p.p.m.
Tuning steps
Software defined
Filters
-

Receiver

Modulations
AM   AM-sync   FM   N-FM   W-FM   CW   USB   LSB   DSB   Multiple (Software defined)
Sensitivity
0.3 µV
Selectivity
-
Receiver system
Direct down conversion, software defined
IF-frequencies
Software defined
Image rejection
-
Audio output
None

Transmitter

Modulations
-
RF-Output
-

Connections

Antenna
SMA
Impedance
50Ω

Electrical

Power requirements
5 V DC (USB 2.0)
Current drain RX
640 mA max
TX
-

Physical

Dimensions (w×h×d)
64 × 24 × 112 mm (2.52 × 0.94 × 4.41 in)
Weight
300 gr (10.6 oz)
Form factor
Headless
Manufactured
Between 2017 and 20xx in Germany
MPN

Other features

Memories
10000 channels in 10000 bank(s)
Usage
Amateur / Ham radio operators
Features + options
Spectrum scope bandwidth up to 62.5 MHz
14-bit, 125 MHz ADC
Aluminium case
Client-Server application possible (remote control)
