The Alinco DJ-X11E has a gapless range of 50 kHz - 1300 MHz. The DJ-X11EGR has has some gaps to satisfy regional legislation. The GR's ranges are 0.522-1.62 / 53.75-67.75 / 87.6-107.9 / 144-145.99995 / 180.75-229.75 / 430-439.99995 / 476.75-860.75 and 1260-1299.99995 MHz.

Original price in 2010 (UK): GBP 399.00

General characteristics

HAM bands
?
Frequency stability
10 p.p.m. (-10 to +50 °C)
Tuning steps
0.05 / 0.1 / 1 / 5 / 6.25 / 8.33 / 10 / 12.5 / 15 / 20 / 25 / 30 / 50 / 100 / 125 / 150 / 200 / 500 / 1000 kHz kHz
Memories
1200 channels in 1 bank(s)

Receiver

RX-range
0.05-1300 MHz (cellular blocked in the US)
Modulations
AM   FM   W-FM   CW   USB   LSB
Sensitivity
0.050-0.531MHz (AM): 5dBμ (10dB S/N)
0.531-1.62MHz (AM): 2dBμ (10dB S/N)
1.62-76MHz (AM): -5dBμ (10dB S/N)
1.62-76MHz (SSB,CW): -10dBu (10dB S/N)
1.62-76MHz (FM): -15dBμ (12dB SINAD)
76-108MHz (WFM): -3dBμ (12dB SINAD)
108-136MHz (AM): -6dBμ (10dB S/N)
136-174MHz (FM): -14dBμ (12dB SINAD)
175-221.75MHz (WFM): -6dBμ (12dB SINAD)
221.8-336MHz (AM): 0dBμ (10dB S/N)
336-475.75MHz (FM): -13dBμ (12dB SINAD)
475.75-770MHz (WFM): -13dBμ (12dB SINAD)
770-1260MHz (FM): -9dBμ (12dB SINAD)
1260-1300MHz (FM): -6dBμ (12dB SINAD)
Selectivity
AM/FM: -6dB/12 kHz or more, -60 dB / 35 kHz or less
SSB/CW: -6dB/2 kHz or more, -50 dB / 7.5 kHz or less
WFM: -6dB/180 kHz ±40 kHz, -20 dB / 470 kHz or less
Filters
?
Receiver system
AM/SSB/CW/FM: Triple-conversion WFM: Double-conversion AM/FM: Double-conversion
IF-frequencies
AM/SSB/CW/FM
1st: 243.95MHz
2nd: 45.055MHz
3rd: 455kHz
W-FM
2nd: 10.7MHz
AM/FM
1st: 51.65MHz
2nd: 450kHz
Image rejection
?
Audio output
100 mW

Connections

Antenna
SMA + Built-in ferrite bar
Impedance
50 Ω
Other
-

Electrical

Power requirements
5.4 ~ 6V DC, Standard battery: 4.5V (AA battery), 3.7V (Lithium ion battery)
Current drain RX
130-180 mA
TX
-

Physical

Dimensions (w×h×d)
61 × 106 × 38 mm (2.40 × 4.17 × 1.50 in) (projection exclusive)
Weight
235 gr (8.3 oz) (antenna and lithium ion battery pack inclusive)
Form factor
Handheld
Manufactured
Between 2010 and 201x in Japan

Other features

Usage
Amateur / Ham radio operators
Features + options
- Inversion scramble decoder option (DJ-X11E only)
- CTCSS/DCS
- Bug detector
- IQ signal output that
can be used with 3rd-party software to operate as a software defined radio
- 10.7 MHz IF-output
- Twin RX
Accessories
-
RigReference ID
5142
MPN
ALINCO-DJ-X000011

Manuals, diagrams and brochures

Alinco DJ-X11 Instruction manual PDF - Unknown size, submitted by RigReference
Alinco DJ-X11 Service manual PDF - Unknown size, submitted by RigReference
