General characteristics

HAM bands
80m  60m  40m  30m (WARC)  20m  17m (WARC)  15m  12m (WARC)  11m (CB)  10m
Frequency stability
?
Tuning steps
Not applicable
Memories
None

Transmitter

TX-range
3.5-29.7 MHz
Modulations
All mode
RF-output
160 W (3.5-21 MHz), 140 W (28 MHz)

Connections

Antenna
SO-239
Impedance
50Ω
Other
-

Electrical

Power requirements
12-16V DC
Current drain RX
?
TX
15 A

Physical

Dimensions (w×h×d)
123 × 107 × 265 mm (4.84 × 4.21 × 10.43 in) including protrusions
Weight
2.30 kg (5.1 lbs)
Form factor
Base Station
Manufactured
Between 19xx and 19xx in Japan

Other features

Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-
RigReference ID
5241
MPN
KENWOOD-TL-000120

Manuals, diagrams and brochures

Kenwood TL-120 Service Manual PDF - Unknown size, submitted by RigReference
