Later models (Eddystone EB-35 Mk II and Eddystone EB-35 Mk III (Statesman)) came equipped with an additional FM IF amplifier using an OC171.
H.R.H. The Prince of Whales had one of these sets fitted to his car.

General characteristics

HAM bands
160m  80m  60m  40m  30m (WARC)  20m  17m (WARC)  15m
Frequency stability
?
Tuning steps
Continuous
Memories
None

Receiver

RX-range
150-350 / 550-1500 kHz / 1.5-22 / 88-108 MHz
Modulations
AM   CW   SSB
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
Double conversion superheterodyne
IF-frequencies
1st: 10.7 MHz
2nd: 465 kHz
Image rejection
?
Audio output
0.75 W

Connections

Antenna
SO-239
Impedance
75/400Ω
Other
-

Electrical

Power requirements
Mains or 6×U2 (1.5V) battery cells
Current drain RX
?
TX
-

Physical

Dimensions (w×h×d)
317 × 162 × 203 mm (12.48 × 6.38 × 7.99 in)
Weight
?
Form factor
Base Station
Manufactured
Between 1965 and 1970 in Great Britain (Birmingham)

Other features

Usage
Marine / Navy
Features + options
-
Accessories
-
RigReference ID
5443
MPN
EDDYSTONE-EB-000035

Manuals, diagrams and brochures

Eddystone EB35 Mk1 Instruction Manual PDF - 312.8 kB, submitted by RigReference
Eddystone EB35 Test And Inspection Schedule PDF - 604.5 kB, submitted by RigReference
