General characteristics
- HAM bands
- 20m
- Frequency stability
- ?
- Tuning steps
- ?
- Memories
- ?
Receiver
- RX-range
- 14.150-14.350 MHz
14.000-14.100 MHz with optional CW module - Modulations
- CW SSB
- Sensitivity
- <0.5 µV for 12 dB S/N
- Selectivity
- ?
- Filters
- 6 dB at 2.5 kHz
- Receiver system
- Single conversion superhet
- IF-frequencies
- 10 MHz
- Image rejection
- ?
- Audio output
- >1 Watt into 8 Ohms at 10% THD
Transmitter
- TX-range
- 20 m
- Modulations
- CW SSB
- RF-output
- 10 W
Connections
- Antenna
- SO-239
- Impedance
- 50Ω
- Other
- -
Electrical
- Power requirements
- 12-14 V DC
- Current drain RX
- 50-100 mA
- TX
- 2.2 A
Physical
- Dimensions (w×h×d)
- ?
- Weight
- ?
- Form factor
- Mobile
- Manufactured
- Between 20xx and 20xx
Other features
- Usage
- Amateur / Ham radio operators
- Features + options
- -
- Accessories
- -
- RigReference ID
- 5521
- MPN
- MFJ-009420X
Manuals, diagrams and brochures
-
No documents available for this particular model.
- Upload relevant documents
Reviews & stories
| Rating | Title | Submitted |
|---|---|---|
| what a wonderfull green radio | 13 years ago by zs6djd | |
| zs6djd South Africa | 13 years ago by zs6djd |
New and second-hand prices
Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used MFJ 9420X. Just bought or sold this model? Let us know what you traded it for and help other ham operators!
These estimates are based on the following prices:
