General characteristics

HAM bands
40m  30m (WARC)  20m  6m
Frequency stability
?
Tuning steps
?
Memories
16 channels in 1 bank(s)

Receiver

RX-range
5.9-16 MHz
Modulations
CW
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
?
IF-frequencies
IF-DDS: 60 MHz
Image rejection
?
Audio output
?

Transmitter

TX-range
7.0-7.3 / 10.1-10.15 / 14.0-14.35 MHz
Modulations
CW
RF-output
5 W @ 13.8 V

Connections

Antenna
BNC
Impedance
?
Other
-

Electrical

Power requirements
9-16 V DC
Current drain RX
70 mA
TX
900 mA

Physical

Dimensions (w×h×d)
88 × 38 × 124 mm (3.46 × 1.50 × 4.88 in)
Weight
280 gr (9.9 oz)
Form factor
Mobile
Manufactured
Between 201x and 201x

Other features

Usage
Amateur / Ham radio operators
Features + options
Sidetone: 700Hz
Keyer: 5-40 wpm adjustable
Auto scan function
LCD display with backlight
Accessories
-
RigReference ID
6246
MPN
YOUKITS-EK-000001C

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Youkits EK-1C. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Youkits EK-1C is around:

  • USD 135.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2017 USD 189.00 New / Mint RigReference
