General characteristics

HAM bands
?
Frequency stability
?
Tuning steps
9 / 10 kHz
Memories
24 channels in 1 bank(s)

Receiver

RX-range
FM 87.5-108 MHz
MW 531-1602 kHz
SW1 2.300-7.800 MHz
SW2 9.100-26.10 MHz
Modulations
AM   FM   SSB
Sensitivity
FM < 10 μV
MW < 3 mV/m
SW < 50 μV
Selectivity
?
Filters
?
Receiver system
PLL
IF-frequencies
?
Image rejection
?
Audio output
ф57mm 16Ω 0.3W

Connections

Antenna
Built-in telescopic
Impedance
50Ω
Other
-

Electrical

Power requirements
3×AA batteries
Current drain RX
?
TX
-

Physical

Dimensions (w×h×d)
145 × 90 × 30 mm (5.71 × 3.54 × 1.18 in)
Weight
280 gr (9.9 oz)
Form factor
Portable
Manufactured
Between 20xx and 20xx

Other features

Usage
Amateur / Ham radio operators
Features + options
Clock
Alarm
Sleep timer
Accessories
-
RigReference ID
5653
MPN
TECSUN-PL-000757A
