This model includings Digital Signal Processing (DPS) on the HF band which helps for the reception of weak signals. Further, the PL880 offers selectable IF bandwidth and lithium ion battery. Available in dark grey.

General characteristics

HAM bands
?
Frequency stability
?
Tuning steps
9 / 10 / 100 kHz
Memories
650 channels in 1 bank(s)

Receiver

RX-range
100-519 / 520-1710 kHz / 1.7-30 / 64-108 MHz
Modulations
AM   AM-sync   FM   W-FM Stereo   SSB
Sensitivity
FM (S / N = 30dB) < 3 μV
MW (S / N = 26dB) < 3mV / m
LW (S / N = 26dB) < 5mV / m
SW (S / N = 26dB) < 20 μV
SSB (S / N = 10dB) < 3 μV
Selectivity
FM > 35 dB (± 200kHz)
MW / LW > 40 dB (± 9kHz)
SW > 40 dB (± 5kHz)
Filters
?
Receiver system
Single / double conversion superheterodyne
IF-frequencies
1st: 55.845 / 10.7 MHz
2nd: 10.7 kHz
Image rejection
?
Audio output
450 mW

Connections

Antenna
Built-in telescopic
Impedance
50Ω
Other
-

Electrical

Power requirements
3.7 v Li-ion battery
Current drain RX
?
TX
-

Physical

Dimensions (w×h×d)
192 × 113 × 33 mm (7.56 × 4.45 × 1.30 in)
Weight
1.50 kg (3.3 lbs) incl. battery
Form factor
Portable
Manufactured
Between 2014 and 20xx in Australia

Other features

Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-
RigReference ID
6389
MPN
TECSUN-PL-000880

Manuals, diagrams and brochures

Tecsun PL-880 Manual PDF - 628.5 kB, submitted by RigReference

Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Tecsun PL-880. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Tecsun PL-880 is around:

  • USD 175.00
  • AUD 225.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2018 USD 176.00 New / Mint RigReference
2018 AUD 226.00 New / Mint RigReference
