Very similar to the Baofeng UV-5R.

General characteristics

HAM bands
70cm
Frequency stability
± 2.5 p.p.m.
Tuning steps
2.5 / 5 / 6.25 / 10 / 12.5 / 25 kHz
Memories
16 channels in 1 bank(s)

Receiver

RX-range
400-470 MHz / FM-radio
Modulations
FM   N-FM
Sensitivity
≤ 0.20 µV (12dB SINAD)
Selectivity
?
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
1 W

Transmitter

TX-range
400-470 MHz
Modulations
FM   N-FM
RF-output
2 W

Connections

Antenna
-
Impedance
50Ω
Other
-

Electrical

Power requirements
3.8 V DC Li-ion, 1800 mAh
Current drain RX
400 mA max
TX
1.5 A max

Physical

Dimensions (w×h×d)
116 × 57 × 35 mm (4.57 × 2.24 × 1.38 in)
Weight
?
Form factor
Handheld
Manufactured
Between 2014 and 201x in China

Other features

Usage
Amateur / Ham radio operators
Features + options
PC programmable
Flashlight
CTCSS / DCS
Voice prompt
Accessories
-
RigReference ID
6084
MPN
BAOFENG-BF-A000005

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Reviews

Rating Title Submitted
Better than expected! 10 years ago by g6iyd

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Baofeng BF-A5. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic price data, today's estimated value of the Baofeng BF-A5 in Good condition is around:

  • USD 14

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2020 USD 18.00 New / Mint eBay
