Expert Electronics SunSDR2 QRP 5 Watt HF & 6m Transceiver

 (0.0/5)  Add a review   View all reviews (0)   Add to my shack



Login or Register to upload images

Remote control (headless) SDR transceiver giving 5W output on all HF HAM bands. Requires a PC to operate.

Price when new: EUR 990.-

Frequency range

RX-range
0.1 to 55 MHz
TX-range
-
HAM bands
160m  80m  60m  40m  30m (WARC)  20m  17m (WARC)  15m  12m (WARC)  11m (CB)  6m  10m
Stability
+/- 2.5 p.p.m.
Tuning steps
Software defined
Filters
-

Receiver

Modulations
AM   AM-sync   N-FM   W-FM   CW   USB   LSB   Multiple (Software defined)
Sensitivity
0.1 µV
Selectivity
-
Receiver system
Direct Down Conversion, SDR
IF-frequencies
Software defined
Image rejection
-
Audio output
Through computer

Transmitter

Modulations
AM   AM-sync   N-FM   W-FM   CW   USB   LSB
RF-Output
5 W

Connections

Antenna
SMA
Impedance
50Ω

Electrical

Power requirements
10 to 15 V DC
Current drain RX
-
TX
3A max

Physical

Dimensions (w×h×d)
165 × 100 × 35 mm (6.50 × 3.94 × 1.38 in)
Weight
500 gr (1.1 lbs)
Form factor
Headless
Manufactured
Between 2017 and 20xx in Russia
MPN
EXPERT-ELECTRONICS-SUNSDR000002-QRP

Other features

Memories
10000 channels in 10000 bank(s)
Usage
Amateur / Ham radio operators
Features + options
Spectrum scope bandwidth up to 60 MHz
16-bit ADC
Accessories
-
