FlexRadio FLEX-6400M HF/VHF SDR transceiver

 (0.0/5)  Add a story   View all stories (0)   Add to my shack



The FlexRadio FLEX-6400M is identical to the FlexRadio FLEX-6400, which is for remote operation only. This model has two independent receivers.

Frequency range

RX-range
30 kHz – 54 MHz
TX-range
160-6 m
HAM bands
160m  80m  40m  30m (WARC)  20m  17m (WARC)  15m  12m (WARC)  11m (CB)  6m  10m
Stability
0.5 p.p.m. TCXO
Tuning steps
1 Hz
Filters
-

Receiver

Modulations
AM   AM-sync   FM   N-FM   CW   USB   LSB   RTTY   DV
Sensitivity
-
Selectivity
-
Receiver system
SDR, Direct Digital Sampling ADC sampling rate: 122.88 Msps, ADC resolution: 16 bit.
IF-frequencies
-
Image rejection
≥ 100 dB
Audio output
1W diagnostic speaker

Transmitter

Modulations
AM   AM-sync   FM   N-FM   CW   USB   LSB   RTTY   DV
RF-Output
1-100W SSB, CW, FM, RTTY, DIGITAL; 1-25W AM

Connections

Antenna
BNC + SO-239
Impedance
50Ω

Electrical

Power requirements
13.8V DC ± 15%
Current drain RX
1.7 A
TX
23 A

Physical

Dimensions (w×h×d)
350 × 171 × 337 mm (13.78 × 6.73 × 13.27 in)
Weight
-
Form factor
Headless
Manufactured
Between 2017 and 20xx in USA
MPN

Other features

Memories
-
Usage
Amateur / Ham radio operators
Features + options
SDR (Software Defined Radio)
Ethernet
2 × USB 2.0
