General characteristics

HAM bands
2m  1.25m  70cm
Frequency stability
± 2.5 p.p.m.
Tuning steps
2.5 / 5.0 / 6.25 / 10.0 / 12.5 / 25.0 kHz
Memories
200 channels in 1 bank(s)

Receiver

RX-range
65-108 / 136-174 / 220-260 / 350-390 (EU/Asia) / 400-520 MHz
Modulations
FM   N-FM
Sensitivity
≤ 0.25 μV (wide band)
≤ 0.35 μV (narrow band)
Selectivity
?
Filters
12.5 / 25 kHz
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
2 W @ 10%

Transmitter

TX-range
136-174 / 220-260 / 350-390 (EU/Asia) / 400-520 MHz
Modulations
FM   N-FM
RF-output
VHF: 10 / 25 W, UHF: 7 / 20 W

Connections

Antenna
SO-239
Impedance
50Ω
Other
-

Electrical

Power requirements
13.6 V DC ±20%
Current drain RX
?
TX
?

Physical

Dimensions (w×h×d)
98 × 35 × 118 mm (3.86 × 1.38 × 4.65 in)
Weight
408 gr (14.4 oz)
Form factor
Mobile
Manufactured
Between 2017 and 20xx in China

Other features

Usage
Amateur / Ham radio operators
Features + options
Multi-color LCD Display
CTCSS / DCS
PC programmable
Accessories
-
RigReference ID
6158
MPN
BAOFENG-UV-000025X4

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Reviews & stories

Rating Title Submitted
The perk and jerks of this rig. 7 years ago by rreh917

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Baofeng UV-25X4. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Baofeng UV-25X4 is around:

  • USD 92.00 ~ USD 90.00
  • CAD 93.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2019 CAD 103.60 New / Mint Mike Caissie
2019 USD 100.00 New / Mint Jeremy
2017 USD 129.00 New / Mint rreh917
