General characteristics

HAM bands
2m  70cm
Frequency stability
± 2.5 p.p.m.
Tuning steps
5 / 6.25 / 8.33 / 9 / 10 / 12.5 / 15 / 20 / 25 / 50 / 100 kHz
Memories
500 channels in 1 bank(s)

Receiver

RX-range
108-137 / 137-174 / 174-400 / 400-480 / 480-999 MHz (Cellular blocked in the US)
Modulations
AM   FM   N-FM   W-FM Stereo
Sensitivity
AM (10 dB S/N)
108-137 MHz: 0.8 µV

FM (12 dB SINAD)
137-150 MHz: 0.2 µV
150-174 MHz: 0.25 µV
174-222 MHz: 0.3 µV
222-300 MHz: 0.25 µV
300-336 MHz: 0.8 µV
336-420 MHz: 0.25 µV
420-520 MHz: 0.2 µV
800-900 MHz: 0.4 µV
900-1000 MHz: 0.8 µV
Selectivity
AM / FM: 12 kHz (-6 dB), 30 kHz (-60 dB)
Filters
?
Receiver system
?
IF-frequencies
1st: 47.25 MHz
2nd: 450 kHz
Image rejection
?
Audio output
3 W

Transmitter

TX-range
144-146 / 430-440 MHz (Europe)
144-148 / 430-450 MHz (USA)
Modulations
FM   N-FM
RF-output
5 / 20 / 50 W

Connections

Antenna
SO-239
Impedance
50Ω
Other
-

Electrical

Power requirements
11.7-15.8 V DC
Current drain RX
0.5 A
TX
12 A max

Physical

Dimensions (w×h×d)
140 × 45 × 193 mm (5.51 × 1.77 × 7.60 in)
Weight
1.10 kg (2.4 lbs)
Form factor
Mobile
Manufactured
Between 200x and 200x

Other features

Usage
Amateur / Ham radio operators
Features + options
GPS-receiver
1200/9600bps APRS® (Automatic Packet Reporting System)
Bluetooth
SD-card slot
Accessories
-
RigReference ID
6161
MPN
YAESU-FTM-000100DR/DE

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Yaesu FTM-100DR/DE. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Yaesu FTM-100DR/DE is around:

  • USD 573.00 ~ USD 181.00
  • CAD 334.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2020 CAD 350.00 Used / Mint Mike Caissie
2020 USD 600.00 Used / Mint Daniel Kondlatsch
2016 USD 300.00 New / Mint nd3q
